Global H-alpha Network

SEL EVENT # 7350 in NOAA AR 2673
Date: 2017, Sep 06
Start Time 1551 UT; Max Time 1556 UT; End Time 1603 UT
Coordinates: S09W38
Flare type: X-ray flare and Optical flare observed in H-alpha
Additional: Greater than or equal to 20 percent umbral coverage
GOES X-ray Class: M2.5 ( Integrated flux from start to end: 1.4E-02 )
Optical: 3N

Below are an MPEG movie for this event, GOES flux plot and data file and several snapshots.


Automaticaly Generated on Wed Sep 6 21:07:15 2017
Please, send questions and comments to Vasyl Yurchyshyn
