Global H-alpha Network

SEL EVENT # 180 in NOAA AR 1261
Date: 2011, Jul 28
Start Time 1759 UT; Max Time 1815 UT; End Time 1822 UT
Coordinates: N15E50
Flare type: X-ray flare and Optical flare observed in H-alpha
Additional: One or more brilliant points
GOES X-ray Class: C1.6 ( Integrated flux from start to end: 9.1E-04 )
Optical: SF

Below are an MPEG movie for this event, GOES flux plot and data file and several snapshots.


Automaticaly Generated on Thu Jul 28 20:03:29 2011
Please, send questions and comments to Vasyl Yurchyshyn
